General Description:

MC-2000 series intelligent digital display programmable controller is an intelligent instrument with 16 sections temperature rises, drops, and constant control program, which developed by adopting the most advanced oversea technology. The series instrument can be worked in conjunction with thermocouple,resistance thermometer sensor,Hall temperature transmitter,YTZ,and DDZ-II,DDZ-III series such as output standard DC signal transmitting instruments, which display temperature,pressure,liquid level,voltage,electric current,and other diversified industrial process variables in form of the figure. The series instrument also increase one route auto-tuning PID output, one route settable timer output, and two routes can be set alarm output: 0~100mA,4~20mA standard direct current signal transmitting output: RS-485,RS-232 standard communication interface: the external incident controls input, etc., various sorts of additional functions.

Features:

Adopting large display screen, and panel frame meets IEC standard

Adopting high elasticity metal shrapnel which has the forward-insert assembled structure

Adopting SMT technique, switch power supply,dual-channels PID auto-tuning algorithm,electromagnetism compatible design with the combination of hardware and software, and others advanced technology and producing process.
